Bulletin 161
18
Parameter
number Function Basic
value Setting range Input
V/F characteristics / boost
A41 Boost select 00 00: Man. boost
01: Auto boost
A42 Manual boost 11 0 – 99
A43 Max. boost at % of base frequency 10 0 - 50%
A44 V/F select 00 00: Constant
01: Variable
A45 Maximum output voltage 100 50 - 100%
DC brake
A51 DC Brake active / inactive 00 00: inactive
01: active
A52 DC Brake
Starting frequency 0.5 0.5 – 10 Hz
A53 DC Brake
Waiting time 0.0 0 - 5 s
A54 DC Brake
Braking torque 0 0 - 100%
A55 DC Brake
Braking time 0.0 0 - 60 s
Operating frequency range
A61 Maximum Frequency 0.0 0.5 - 360 Hz
A62 Minimum Frequency 0.0 0.5 - 360 Hz
A63 1
st
Skip Frequency 0 0 - 360 Hz
A64 1
st
Skip Frequency Band 0.5 0 - 10 Hz
A65 2
nd
Skip Frequency 0 0 - 360 Hz
A66 2
nd
Skip Frequency Band 0.5 0 - 10 Hz
A67 3
rd
Skip Frequency 0 0 - 360 Hz
A68 3
rd
Skip Frequency Band 0.5 0 - 10 Hz
