Bulletin 161
17
Parameter
number Function Basic
value Setting range Input
Basic parameters
A01 Frequency command select 01 00: Frequency Pot
01: Input O/OI
02: Param.
F01/A20
A02 Start command select 01 01: Input [FW]/[RV]
02: RUN key
A03 Base frequency 50 50 - 360 Hz
A04 Maximum frequency 50 50 - 360 Hz
Analog input reference adjustment
A11 Frequency at the minimum set value 0 - 360 Hz
A12 Frequency at the maximum set value 0 0 - 360 Hz
A13 Analog input minimum 0 0 - 100%
A13 Analog input maximum 100 0 - 100%
A15 Start condition 01 00: Minimum speed
01: 0 Hz start
A16 Analog input filter setting 8 1 (max. filter,
slow response) to
8 (min. filter,
fast response)
Pre-set frequencies
A20 Frequency command if 02 has been entered
under parameter
A01
0.0 0 - 360 Hz
A21 1. Preset Frequency 0 0 - 360 Hz
A22 2. Preset Frequency 0 0 - 360 Hz
A23 3. Preset Frequency 0 0 - 360 Hz
A24 4. Preset Frequency 0 0 - 360 Hz
A25 5. Preset Frequency 0 0 - 360 Hz
A26 6. Preset Frequency 0 0 - 360 Hz
A27 7. Preset Frequency 0 0 - 360 Hz
A28 8. Preset Frequency 0 0 - 360 Hz
A29 9. Preset Frequency 0 0 - 360 Hz
A30 10. Preset Frequency 0 0 - 360 Hz
A31 11. Preset Frequency 0 0 - 360 Hz
A32 12. Preset Frequency 0 0 - 360 Hz
A33 13. Preset Frequency 0 0 - 360 Hz
A34 14. Preset Frequency 0 0 - 360 Hz
A35 15. Preset Frequency 0 0 - 360 Hz
A38 Jog Frequency 1.0 0.5 – 9.9 Hz
A39 Jog Stop Mode 00 00: Coast
01: Ramp
02: DC brake
