Chapter 8, Viewing the, Viewing the option module web pages – Rockwell Automation 20-750-PNET2P Profinet Dual Port Option Module User Manual
Page 65
Rockwell Automation Publication 750COM-UM007A-EN-P - January 2013
65
Chapter
8
Viewing the Option Module Web Pages
This chapter provides instructions on how to monitor the PowerFlex 750-Series
drive and its option module by using the module's web interface.
Future enhancements may result in option module web pages that look different
than the examples shown in this chapter.
Enabling the Option Module
Web Pages
After the option module is configured and operating, you can view its web pages.
They present information about the module, the drive to which it is connected,
and the other DPI devices connected to the drive such as a HIM.
By default the option module web pages are disabled. To enable the option
module web pages, set
Device Parameter 19 - [Web Enable] to ‘1’ (Enabled) and
then reset the option module for the change to take effect.
Viewing the Web Pages
The option module can be configured to automatically send email messages to
desired addresses when selected drive faults occur and/or are cleared, and/or
when the option module takes a communication or idle fault action.
Bit 0 of
Device Parameter 20 - [Web Features] can be used to protect the
configured settings. For more details, see
Configure E-mail Notification Web
1.
On a computer with access to the Profinet network on which the drive/
option module is installed, launch a web browser such as Microsoft
™
Internet Explorer, version 5.0 or later.
The computer can access the option module web pages if it is connected to:
• The same network as the drive/option module.
• A network with access to the drive/option module's network via a
gateway device (for example, a router).
Topic
Page
Enabling the Option Module Web Pages
Process Display Pop-up Dialog Box
Profinet Configuration Web Page
