Rockwell Automation Publication 750COM-UM007A-EN-P - January 2013 59
Troubleshooting Chapter 7
27 DL To Net 01 Val The present value of respective Host DL To Net xx parameter being received from the drive by this option module. (If
not using a Datalink, its respective value should be zero.)
28 DL To Net 02 Val
29 DL To Net 03 Val
30 DL To Net 04 Val
31 DL To Net 05 Val
32 DL To Net 06 Val
33 DL To Net 07 Val
34 DL To Net 08 Val
35 DL To Net 09 Val
36 DL To Net 10 Val
37 DL To Net 11 Val
38 DL To Net 12 Val
39 DL To Net 13 Val
40 DL To Net 14 Val
41 DL To Net 15 Val
42 DL To Net 16 Val
43 DPI Rx Errs The present value of the DPI Receive error counter.
44 DPI Rx Errs Max The maximum value (since reset) of the DPI Receive Error counter.
45 DPI Tx Errs The present value of the DPI Transmit error counter.
46 DPI Tx Errs Max The maximum value (since reset) of the DPI Transmit Error counter.
47 Boot Flash Count Number of times the boot firmware in the option module has been updated.
48 App Flash Count Number of times the application firmware in the option module has been updated.
49 P1 ID Indicates port number on option module network port 1.
50 P1 Rx Tot Bytes Total count of bytes received on option module network port 1.
51 P1 Rx Tot Frms Total count of frames received on option module network port 1.
52 P1 Rx Good Frms Count of good frames received on option module network port 1.
53 P1 Rx Unicasts Count of unicasts received on option module network port 1.
54 P1 Rx Multicst Count of multicasts received on option module network port 1.
55 P1 Rx Broadcst Count of broadcasts received on option module network port 1.
56 P1 Rx Unk Mlcst Count of unknown multicasts received on option module network port 1.
57 P1 Rx Unk Uncst Count of unknown unicasts received on option module network port 1.
58 P1 Rx Err Count of receive errors on option module network port 1.
59 P1 Rx Discards Count of received frames that were discarded on option module network port 1.
60 P1 Tx Tot Bytes Total count of bytes transmitted on option module network port 1.
61 P1 Tx Tot Frms Total count of frames transmitted on option module network port 1.
62 P1 Tx Unicasts Count of unicasts transmitted on option module network port 1.
63 P1 Tx Multicst Count of multicasts transmitted on option module network port 1.
64 P1 Tx Broadcst Count of broadcasts transmitted on option module network port 1.
Table 4 - Option Module Diagnostic Items (Continued)
No. Name Description
