Chapter 7 Troubleshooting
65 P1 Tx Collision Count of transmitted frames in which there was a collision on option module network port 1.
66 P1 Tx Err Count of transmit errors on option module network port 1.
67 P1 Tx Discards Count of transmitted frames that were discarded on option module network port 1.
68 P2 ID Indicates port number on option module network port 2.
69 P2 Rx Tot Bytes Total count of bytes received on option module network port 2.
70 P2 Rx Tot Frms Total count of frames received on option module network port 2.
71 P2 Rx Good Frms Count of good frames received on option module network port 2.
72 P2 Rx Unicasts Count of unicasts received on option module network port 2.
73 P2 Rx Multicst Count of multicasts received on option module network port 2.
74 P2 Rx Broadcst Count of broadcasts received on option module network port 2.
75 P2 Rx Unk Mlcst Count of unknown multicasts received on option module network port 2.
76 P2 Rx Unk Uncst Count of unknown unicasts received on option module network port 2.
77 P2 Rx Err Count of receive errors on option module network port 2.
78 P2 Rx Discards Count of received frames that were discarded on option module network port 2.
79 P2 Tx Tot Bytes Total count of bytes transmitted on option module network port 2.
80 P2 Tx Tot Frms Total count of frames transmitted on option module network port 2.
81 P2 Tx Unicasts Count of unicasts transmitted on option module network port 2.
82 P2 Tx Multicst Count of multicasts transmitted on option module network port 2.
83 P2 Tx Broadcst Count of broadcasts transmitted on option module network port 2.
84 P2 Tx Collision Count of transmitted frames in which there was a collision on option module network port 2.
85 P2 Tx Err Count of transmit errors on option module network port 2.
86 P2 Tx Discards Count of transmitted frames that were discarded on option module network port 2.
87 HW Addr 1 Decimal value of each byte in the option module's hardware address. This is configured during factory production and
it cannot be changed by the user.
88 HW Addr 2
89 HW Addr 3
90 HW Addr 4
91 HW Addr 5
92 HW Addr 6
93 P1-HW Addr1 Decimal value of each byte in the option module’s Port 1 hardware address. This is configured during factory
production and it cannot be changed by the user.
94 P1-HW Addr2
95 P1-HW Addr3
96 P1-HW Addr4
97 P1-HW Addr5
98 P1-HW Addr6
Table 4 - Option Module Diagnostic Items (Continued)
No. Name Description
255:255:255:255:255:255
[HW Addr 1]
[HW Addr 2]
[HW Addr 3]
[HW Addr 4]
HW Addr 5]
[HW Addr 6]
