Catalog Number Explanation The PowerFlex 40 Adjustable Frequency AC Standard Configured Drives
catalog numbering scheme is shown below.
Position
1-3 4 5 6-8 9 10 11 12 13 14 15 16+
23B – D 4P0 D 1 0 4 N N – P6
a b c d e f g h i j
a
Drive
Code Type
23B PowerFlex 40
b
Voltage Rating
Code Voltage Ph.
D 480V ac 3
c
Amp Rating
480V 60Hz Input
Code Amps kW (Hp)
1P4 1.4 0.4 (0.5)
2P3 2.3 0.75 (1.0)
4P0 4.0 1.5 (2.0)
6P0 6.0 2.2 (3.0)
010 10.5 4.0 (5.0)
012 12 5.5 (7.5)
017 17 7.5 (10)
024 24 11 (15)
d
Enclosure
Code Enclosure
C NEMA/UL Type 4X ‡
D NEMA/UL Type 4 ‡
‡ The design of the PowerFlex 40 Standard
Configured Drive supports indoor and outdoor
applications that are not in direct sunlight.
f
Emission Class
Code Rating
0 Not Filtered
g
Version
Code Version
4 RS485 (Standard)
C ControlNet
D DeviceNet
E EtherNet/IP
P PROFIBUS DP
h
Code Rating
N Reserved
i
Code Rating
N Reserved
e
HIM
Code Interface Module
1 Fixed Keypad on Drive
F
Fixed Keypad on Drive and LCD
Display with Digital Speed Control
HIM on Enclosure Door
(22-HIM-C2S)
This option changes the enclosure rating to
indoor only.
j
Options
Code Description
-E22
DeviceNet Quick Disconnect
(Bottom)
-E23
DeviceNet Quick Disconnect (Left
Side)
-P3 Motor Circuit Protector
-P3T
Motor Circuit Protector (Customer
wiring into top of device)
-P6 Disconnect Switch - Fused
-P6T
Disconnect Switch - Fused
(Customer wiring into top of device)
-R3
DeviceNet I/O (4 In/2 Out) w/Spring
Return HOA and Power Disconnect
Aux. Contact
-R4 DeviceNet Point I/O w/IB4 (4 Inputs)
-R5
-R3 plus 4 I/O Quick Disconnects
and (1) 24V DC Receptacle
-S1
Hand/Off/Auto S.S.
(Start/Stop/Speed Ref.)
-S4 Auto/Manual S.S. (Speed Ref.)
-S7 Start and Stop P.B.
-S8 Forward/Reverse S.S.
-S18
Door Mounted Local Speed Pot (1-
Turn)
-S20
Local/Remote and Local Control
Off/Run Forward Selector Switches
-S21
Local/Off/Remote with 1 N.O.
Interposing Relay
-S22
Spring Return Hand/Off Auto S.S.
(Start/Stop/Speed Ref.)
-S23 Clear Fault P.B.
