Rockwell Automation Publication 23B-IN001K-EN-P - September 2013 57
Appendix
B
Replacement Parts
The following tables provide spare part information for the PowerFlex 40
configured AC drive.
Spare Parts Lists Table 8 - Components
Description Designation Voltage HP Part Number Manufacturer
Motor Circuit
Protector
Option P3 or P3T MCP1 480V AC 0.5 140M-C2E-B40
(2)
Allen-Bradley
1.0 140M-C2E-B63
(2)
Allen-Bradley
2.0 140M-D8E-C10
(2)
Allen-Bradley
3.0 140M-D8E-C16
(2)
Allen-Bradley
5.0 140M-F8E-C25
(2)
Allen-Bradley
7.5 140M-F8E-C25
(2)
Allen-Bradley
10 140M-F8E-C32 (2) Allen-Bradley
15 140M-F8E-C45 (2) Allen-Bradley
Replacement Kit (1)
Option P3
MCP1 480V AC 0.5 363326 Allen-Bradley
1.0 363333 Allen-Bradley
2.0 363337 Allen-Bradley
3.0 363341 Allen-Bradley
5.0 363345 Allen-Bradley
7.5 363349 Allen-Bradley
10 363353 Allen-Bradley
15 363357 Allen-Bradley
Operator Handle
Option P3 or P3T MCP1 480V AC 0.5…5
7.5…15 190-HS4
140M-C-DN66 Allen-Bradley
Allen-Bradley
Operator Handle
Adaptor Option P3 or
P3T MCP1 480V AC 0.5…15 140M-D-HA Allen-Bradley
Operator Shaft Option
P3 or P3T MCP1 480V AC 0.5…5
7.5…15 194R-NX12
140M-C-DS Allen-Bradley
Allen-Bradley
Operator Terminal
Markings MCP1 480V AC 0.5…5.0 A46006-086-01
(2)
140M-C-TE
(2)
Allen-Bradley
Allen-Bradley
7.5…15 A46006-091-01
(2)
140M-F-TE (2)
Allen-Bradley
Allen-Bradley
Disconnect Switch
Option P6 or P6T DS1 480V AC 0.5…10 194R-J30-1753 Allen-Bradley
15 194R-J60-1753 Allen-Bradley
Operator Handle
Option P6 or P6T DS1 480V AC 0.5…15 194R-PB Allen-Bradley
