Rockwell Automation Publication 23B-IN001K-EN-P - September 2013 11
PowerFlex 40 Standard Configured Drive Standard Features and Options Chapter 1
Communication Options DeviceNet (Position 12, Code D)
The DeviceNet option is drive mounted and consists of the DeviceNet
communication adaptor (22-COMM-D) and adaptor cover (22B-CCB for
frame B drives or 22B-CCC for frame C drives). When DeviceNet is present, no
other communication option is available other than the HIM. When used as a
slave, the HIM will have limited functionality. For details related to the
DeviceNet option, refer to the PowerFlex DeviceNet Adapter User Manual,
publication
22COMM-UM003 .
To review this schematic see Figure 1 on page 28 and Figure 3 on page 30 .
EtherNet/IP (Position 12, Code E)
The EtherNet/IP option is drive mounted and consists of the EtherNet/IP
communication adaptor (22-COMM-E) and adaptor cover (22B-CCB for
frame B drives or 22B-CCC for frame C drives). When EtherNet/IP is present,
no other communications option is available other than the HIM. When used as
a slave, the HIM will have limited functionality. For details related to the
EtherNet/IP option, refer to the PowerFlex EtherNet/IP Adapter User Manual,
publication
22COMM-UM004 .
To review this schematic see Figure 1 on page 28 and Figure 3 on page 30 .
PROFIBUS (Position 12, Code P)
The PROFIBUS option is drive mounted and consists of the PROFIBUS
communication adaptor (22-COMM-P) and adaptor cover (22B-CCB for
frame B drives or 22B-CCC for frame C drives). When PROFIBUS is present,
no other communication option is available other than the HIM. When used as a
slave, the HIM will have limited functionality. For details related to PROFIBUS
option, refer to the PowerFlex PROFIBUS Adapter User Manual, publication
22COMM-UM005 .
To review this schematic see Figure 1 on page 28 and Figure 3 on page 30 .
ControlNet (Position 12, Code C)
The ControlNet option is drive mounted and consists of the ControlNet
communication adaptor (22-COMM-C) and adaptor cover (22B-CCB for
frame B drives or 22B-CCC for frame C drives). When ControlNet is present,
no other communication option is available other than the HIM. When used as a
slave, the HIM will have limited functionality. For details related to ControlNet
option, refer to the PowerFlex ControlNet Adapter User Manual, publication
22COMM-UM006 .
To review this schematic see Figure 1 on page 28 and Figure 3 on page 30 .
