Installing the Adapter 2-7
1. Verify that the adapter will have a unique address on the network. If a
new address is needed, reset its switches (refer to Commissioning the
Adapter in this chapter).
2. Close the door or reinstall the cover on the drive. The status
indicators can be viewed on the front of the drive after power has
been applied.
3. Apply power to the PowerFlex drive. The adapter receives its power
from the connected drive. When you apply power to the product the
status indicators should be green after an initialization. If the status
indicators go red, there is a problem. Refer to
Chapter 7 ,
Troubleshooting .
4. If the node address switches are set to “00,” use a configuration tool
to set the node address parameters in the adapter (refer to Chapter 3 ,
Configuring the Adapter ).
5. Apply power to the master device and other devices on the network.
Applying Power
!
ATTENTION: Risk of equipment damage, injury, or death exists.
Unpredictable operation may occur if parameter settings and switch
settings are not compatible with your application. Verify that settings
are compatible with your application before applying power to the
drive.
