Page 41
Fiber-Classic
Door Panel
Dimensions
Comp 4
2014 (BOOK SIZE)
4.41
8/0 Fiber-Classic Oak
Flush-Glazed Doors
95-1/4”
80-1/16”
5-9/16”
24”
9-5/8”
78-13/16”
14-1/4”
This space intentionally left blank.
8’ Full Lite Flush-Glazed
(Slab-FN82014)
15-1/2”
4-1/4”
Note:
2/0 Only.
For Optional Grille Locations,
See Arch 1.
Daylight Opening: 14-1/4" x 78-13/16"
(1123 sq.in.)
