Page 36
Fiber-Classic
Door Panel
Dimensions
4.36
2014 (BOOK SIZE)
Comp 4
8/0 Fiber-Classic Oak Doors
Size
A
B
C
D
E
F
2/8
32”
3-15/16” 82-1/8”
8”
5-1/8”
2/8 Impact
32”
4-1/16”
81-7/8”
8-1/8”
5-1/4”
2/10
34”
24-1/8”
4-15/16” 82-1/8”
8”
5-1/8”
2/10 Impact
34”
23-7/8”
5-1/16”
81-7/8”
8-1/8”
5-1/4”
3/0
36”
24-1/8”
5-15/16” 82-1/8”
8”
5-1/8”
3/0 impact
36”
23-7/8”
6-1/16”
81-7/8”
8-1/8”
5-1/4”
A
C
95-1/4”
F
D
E
B
Size
A
B
C
D
E
F
2/6
30”
22-1/8”
3-15/16”
82-1/8”
8”
5-1/8”
2/6 Impact
30”
21-7/8”
4-1/16”
81-7/8”
8-1/8”
5-1/4”
2/8
32”
22-1/8”
4-15/16”
82-1/8”
8”
5-1/8”
2/8 Impact
32”
21-7/8”
5-1/16”
81-7/8”
8-1/8”
5-1/4”
A
C
95-1/4”
F
D
E
B
Note:
For Optional Grille
Locations, See Arch 1.
8’ Full Lite Flush
(8084, 2280)
(Impact - 808H, 818H, 828H)
(Slab - FCO8010)
(Impact - FCO8010H)
8’ Full Lite Flush
(8084N, 2080)
(Impact - 808NH, 818NH, 828NH)
(Slab - FCO8010)
(Impact - FCO8010H)
Note:
For Optional Grille
Locations, See Arch 1.
Daylight Opening: 20-15/16" x 78-15/16"
(for 1" glass) (1653 sq.in.)
Daylight Opening: 21-1/8" x 79-1/8"
(for 1/2" glass) (1672 sq.in.)
Daylight Opening: 18-15/16" x 78-15/16"
(2080 for 1" glass) (1495 sq.in.)
Daylight Opening: 19-1/8" x 79-1/8"
(2080 for 1/2" glass) (1513 sq.in.)
24-1/8”
23-7/8”
