VENTEV INNOVATIONS BTRM200 Battery Test Remote Monitoring System – User Guide V1.0
48
To clear or enable write a "1", or to disable write a "0".
An xample to reset battery data, g10v01 q00 start 0 stop 0 value 1, would be to issue
an application layer write command of the form:
c5 02 0a 01 00 00 00 01
Point Description State Value State Value
0 Battery Data Reset Write to Enable 0x81 Write to Disabled 0x01
1 Battery LV Disconnect Enable Write to Clear 0x81 Cleared 0x01
2 Battery Test Enable Write to Start 0x81 Write to Stop 0x01
3 Battery Start / Stop Test Write to Start 0x81 Write to Stop 0x01
9.1.3.9. Events
When Events are generated, they are reported via unsolicited messaging (if
enabled), or queue to the event list for reading when polling for Class 2 data, or
reading Binary events. Event points correspond to Binary Input Points.
Point Description State Value
1 Low Battery Capacity Event Tripped Event 0x81
2 Low Battery Voltage Event Tripped Event 0x81
4 Aux IO Channel 1 Event Tripped Event 0x81
5 Aux IO Channel 2 Digital In Tripped Event 0x82
9.1.3.10.
9.2. Mod Bus
- expected Q3/2013
