TerraWave M6140140MP1D0006 User Manual

Wireless infrastructure

Applications

• Stadiums

• Campuses

• City Centers

• Convention Centers

• Other Large Venues

Compatible Radios

• Cisco

• Aruba

• Juniper

• Meru

• Motorola

• Others

Increase Capacity and Coverage

Wi-Fi coverage in stadiums, campuses and other large venues can be a

challenge because of the large concentration of users simultaneously

accessing the network, often through multiple devices. Wireless systems

are being pushed to their limits and high-density Wi-Fi networks are
becoming the norm. The new TerraWave Solutions

High-Density

Antennas significantly improve service quality by increasing capacity and

coverage directly where it’s needed.

TerraWave’s highest-performing High-Density 2.4/5 GHz 14 dBi Patch

Antenna is designed for wireless networks operating in the 2.4 GHz and

5 GHz frequency range in both indoor and outdoor applications. The

antenna uses a narrow 35-degree beamwidth at 2.4/5 GHz, minimizing

channel-to-channel interference which in turn leads to increased

capacity.
The antenna also features higher gain which enables greater

distance between antenna and the users without sacrificing network

performance. Greater distance offers venue operators greater flexibility
in antenna placement for optimum performance and security.

TerraWave High-Density 2.4/5 GHz 14 dBi

Patch Antenna

With N-Style Jack Connector

wireless infrastructure
