5 5 Direct Operate
13 D Cold Restart
15 F Initialize Data
20 14 Enable Unsolicited
21 15 Disable Unsolicited
129 81 Response
130 82 Unsolicited Response
9.1.3.1.1. Enable Disable Unsolicited Event Status
BTRM allows enable and disable of unsolicited events. Status can be
read from Binary Point 3
9.1.3.2. Groups and Variations
Object /Group Object /Group Type Variation Description
01 Binary Input Status Static 02 1 byte input status with flag
30 Analog Input Status Static 04 16 bits without flag
10 Binary Output Status Static 02 1 byte output status with flag
10 Binary Output Write Static 01 Write using q00 start = stop
40 Analog Output Status Static 02 16 bits with flag
41 Analog Output Static 02 16 bits with flag 0x01
60 Class 1 Static Data Static 01 Class 1 Data
60 Class 2 Event Data Static 02 Class 2 Data
9.1.3.3. Qualifiers
Qualifiers (Hex) Used In a request Range Index
00 a range of points or single point 8 bits 8 bits
06 all points range and index 8 bits 8 bits 8 bits
17 list of unrelated points 8 bits 8 bits
9.1.3.4. Binary Input Status Points
Point Description State Value
0 Low Battery Capacity Low 0x81
1 Low Battery Voltage Low 0x81
2 DNP3 Unsolicited Enabled Enabled 0x81
3 Aux IO Channel 1 Digital In Tripped 0x81
4 Aux IO Channel 2 Digital In Tripped 0x81
5 Any Fault Flag Tripped 0x81
