VENTEV INNOVATIONS BTRM200 Battery Test Remote Monitoring System – User Guide V1.0
47
IO1 Function Control Values 0,1,2,3,4
Read Group 40 Variation 2
16bit Analog with
flag
Direct Operate Group 41 Variation 2
16bit Analog with
flag
Direct Op Value
0 Analog
1 Digital Input Alarm if < 1v
2 Digital Input Alarm if > 2v
Low Capacity Alarm
3 Digital Out NC
4 Digital Out NO
IO2 Function Control Values 0,1,2
Read Group 40 Variation 2
16bit Analog with
flag
Direct Operate Group 41 Variation 2
16bit Analog with
flag
Direct Op Value
0 Analog
1 Digital Input Alarm if < 1v
2 Digital Input Alarm if > 2v
9.1.3.7. Binary Output Status Point
Point Description State Value State Value
0 Battery Data Reset Session has Data 0x81 Data Empty 0x01
1 Battery LVD Status LVD is enabled 0x81 LVD disabled 0x01
2 Battery Test Enable Test is enabled 0x81 Test is disabled 0x01
3 Battery Start Test Test running 0x81 Test not running 0x01
9.1.3.8. Binary Output Write to Points
Binary output points can be written to directly using Group 10 variation 01, using
Qualifier 0x00 (8 bit index and range).
Points must be written to individually, using matching start and stop values,
followed by the binary value "1" or "0" (See DNP_IEE-1815-2023 11.9.4.6)
