VENTEV INNOVATIONS BTRM200 Battery Test Remote Monitoring System – User Guide V1.0
46
9.1.3.5. Analog Input Status Points
Point Description Units
0 Battery Voltage millivolts 0 to3200 mv
1 Charger Voltage millivolts 0 to3200 mv
2 Battery Current ±milliamps ± 32000 ma
3 Temperature ±°C
4 Battery Minimum Runtime Minutes 0 to 3200 minutes
5 Battery Runtime Estimate Hours
6 Battery Test Temperature ±°C
7 Battery Test Schedule Time Hours 0 to 500 Hrs
8 Battery Test Next Time Hours 0 to 500Hrs
9 Aux IO Channel 1 Voltage millivolts 0 to3200 mv
10 Aux IO Channel 2 Voltage millivolts 0 to3200 mv
11 Firmware Version format xx.xx -> 130 = v1.30
9.1.3.6. Analog Output Status Points
Point Description State
0 Battery Minimum Runtime Minutes 0 to 3200 minutes
1 Battery Test Schedule Time Hours 0 to 500Hrs
2 Battery Test Next Test Time Hours 0 to 500Hrs
3 Aux IO Channel 1 Config 1,2,3 (see below)
4 Aux IO Channel 2 Config 1,2,3,4,5 (see below)
5 System Selection 12V /24V 1,2 1= 12v, 2 =24v
