Chapter 5 Setting Up the ETC2002 Configuring Data Server
ETC2002 Network Communicator 47
5. Specify the start device register and the number of registers in the write
data exchange:
Write block start register address: 200
New:
Number of registers: 10
New:
6. Enable polling for the write data exchange if you want to start exchange
operations:
Polling: disabled
New [y/n]:
7. Specify the device status register and a register mask for a status event
exchange:
Status register address: 400
New:
Status register mask: 0xC000(HEX)
New:
8. Enable polling for the status event exchange if you want to start
exchange operations:
Status polling: disabled
New [y/n]:
9. Enable the auto-reset option, if you wish the register to be automatically
cleared after it has been read:
Status register auto-reset: disabled
New [y/n]:
10. Enable using Modbus Request 1 if you wish the register to be read as
coils:
Register type: holding
New [coil/holding]:
Data server >
11. Type q to quit the Data server menu.
Using PAS
Data Server Options
To enter the Setup dialog, select the ETC2002 site from the list box on the
PAS toolbar, and then select ETC2002 Setup from the Meter Setup menu.
