Chapter 5 Setting Up the ETC2002 Configuring Data Server
46 ETC2002 Network Communicator
Data Server Options
To view the Data server options, type i and press Enter.
Data server>i
Data Server Configuration
------------------------------------
Data server disabled
Continuous polling disabled
Polling interval 1 min
Logging interval 1 (x1min)
To setup or change the Data server options, type p and press Enter. To
change an option, type your new setting after the prompt and press Enter. To
leave the setting unchanged, just press Enter. Refer to the table below for
the available options and their explanation.
Data server>p
Data server: disabled
New [y/n]:
Continuous polling: disabled
New [y/n]:
Polling interval: 1 min
New:
Logging interval: 1 (in polling interval units)
New:
Data Server Exchanges
See Data Server in Chapter 3 for more information on using Data server
exchanges.
To inspect the present configuration (to leave the settings unchanged, just
press Enter) or configure the Data server exchanges:
1. Type
s
and press Enter. The following prompt appears:
Data server>s
Data Exchange No:
2. Type the data exchange number, and then specify the device address,
the start device register and the number of registers in the real-time data
exchange. Note that the real-time, status event and write data
exchanges with the same exchange number are internally linked in the
ETC2002 to the same device address.
Device ID: 1
New:
Start device register address: 256
New:
Number of registers: 1
New:
3. Enable real-time polling for the exchange if you want to start exchange
operations:
Polling: enabled
New [y/n]:
4. Enable updating the real-time clock in the device if you wish to
periodically synchronize its clock with the ETC2002 clock:
RTC update: disabled
New [y/n]:
