Calibrating and Bump Testing the PPM Com-

If the ppm sensor cannot calibrate to the proper value, FAIL
displays along the bottom of the screen and the Gas Tracer
indicates that the ppm sensor failed to calibrate.

The buzzer and alarm lights activate. Press and release the RESET
SILENCE button after the buzzer and lights stop to reset the alarm
and return to the AUTO CAL menu item. Attempt to calibrate
again. If the failure continues, investigate the cause. See
“Troubleshooting” on page 82.

14.Disconnect the humidifier from the probe.

NOTE:

Grasp the humidifier tube assembly by the clear tubing at the
end, not the humidifier tube itself.

15.Use the (SHIFT)▼ button to navigate to the ESCAPE menu item,

then press and release the POWER ENTER button to return to
Measuring Mode.

Performing a Single Calibration

This section describes how to calibrate the PPM combustible gas
sensor using single calibration.

1. To calibrate the ppm sensor using single calibration, use the AIR▲

button to scroll to ONE CAL and press and release the POWER
ENTER button.

2. Fill the gas bag with ppm calibration gas as described in “Filling

the Gas Bag” on page 98.

3. You will be prompted to choose between WET and DRY. Use the

WET setting.

NOTE:

The DRY setting in ONE CAL is for factory use only. Do not
perform a calibration in ONE CAL using the DRY setting.

ppm

MAINTENANCE

FAIL
