95 • Parts List 10,000 ppm Gas Tracer Operator’s Manual
6. Remove the old hydrophobic filters and/or wire mesh disk from
the gasket. A hydrophobic filter is located on either side of the wire
mesh disk.
7. Install the new hydrophobic filters and/or wire mesh disk making
sure a hydrophobic filter is located on each side of the wire mesh
disk.
8. Reinstall the gasket with the parts into the case. Ensure that the
installation stub is lined up with the pump intake in the filter
chamber.
9. Reinstall the filter holder with the cotton dust filter. Align the two
wide tabs on the bottom of the filter holder with the two wide slots
in the case where the filter holder fits. Push the filter holder into the
case and turn it 1/4 turn clockwise until it snaps into place.
Parts List
Table 6 lists part numbers for the Gas Tracer’s replacement parts and
accessories.
Table 6: Parts List
Part Number Description
06-1248RK-03 Calibration kit tubing, 3 foot length
07-2005RK Gasket, filter/screen retaining
13-0112RK Wrist strap
17-1001RK Tapered rubber nozzle
21-1833RK Filter holder, clear plastic
33-0159RK Hydrophobic disk filter
33-1031RK Cotton ball 25 pack, for replacement of cotton dust filter
33-1112RK Wire mesh disk filter
33-2001RK-01 6 inch humidifier tube, for connecting zero air cylinder (if used for a
WET fresh air adjustment) and ppm calibration cylinder to
instrument
47-5027RK Downloading cable, USB/IrDA adapter
49-0115RK AC adapter for charging station
49-1615RK Lithium ion battery pack
49-1616RK Alkaline battery pack without batteries
49-1616RK-01 Battery cover, alkaline battery pack
