Orbit Baby Infant Car Seat and generation-one Base - Manual (Page 24)

46
46
Install the Base
46
Using the Infant Car Seat with the Base
46
Install the Base
47
47
47
Using the Infant Car Seat with the Base
47
1. Make sure the top of the Base and
SmartHub are clear of objects
before docking the Infant Car Seat.
2. Grasp the Infant Car Seat fi rmly
by both Side Handles (Photo B).
Dock the bottom of the Infant Car
Seat into the circular SmartHub of
the Base until you hear and feel a
CLICK
(Photo C).
For increased comfort and ease of use, the
Infant Car Seat can be docked from almost
any angle onto the Base.
3. Rotate the Infant Car Seat until you
hear and feel another CLICK as it
locks into the rear-facing position
(Photo D). The Infant Car Seat will
only lock when rotated into the
rear facing position. Note that the
Hub Locks only
CLICK when the
Release Levers are not pulled.
Docking the Infant Car Seat cont’d
Docking the Infant Car Seat
Never operate your vehicle unless
the Infant Car Seat is LOCKED in
the rear-facing position. Check both
Rotation Indicators on the Base. If
either Rotation Indicator is red, the
Infant Car Seat is not safely locked.
When a Release Lever is pulled,
the Infant Car Seat is not secured
properly to the Base (see Photo A).
Only use the Release Levers when
removing the Infant Car Seat. Do not
allow children to operate the Release
Levers.
PINCH HAZARD: Ensure that your
child’s fi ngers and appendages are
clear of moving parts. When installing
the Infant Car Seat, make sure hands
of other vehicle occupants are clear of
the SmartHub area.
WARNING
!
Death or Serious Injury
can occur
!
B
C
D
A
