clamp arms firmly and locking them in
place (Listen for a
CLICK) (Photo J).
11. If the vehicle seat back is adjustable, lock
the vehicle seat back into the upright
position.
12. Center the car seat on the vehicle seat
between the vehicle LATCH anchorages
(Photo K), making sure the area between
the vehicle LATCH anchorages and the
areas under and behind the car seat are
clear of obstructions.
13. Attach both LATCH connectors to their
corresponding vehicle anchorages on
each side of the car seat. With the
connectors oriented with the logo facing
outward and the UP arrows facing the
roof of the vehicle, push them straight
onto the metal bars until you hear and feel
a
CLICK (Photo L).
14. Pull out on each LATCH connector to
be sure it is locked onto the vehicle’s
anchorage point.
Installing the Car Seat: With LATCH
cont’d
15. Tighten the vehicle belt around the car
seat by pushing down on alternating
sides of the car seat rim while pulling on
the LATCH belt loop to remove all of the
slack (Photo M).
You know that you have reached the
optimal tightness when you tug on the
car seat at the belt path (Photo N) and
the car seat does not move more than
1 in (2.5 cm) in any direction.
If the car seat is loose, remove and re-
install the car seat beginning at Step 11.
16. Close the upper upholstery panel and
install the top tether: See pages 87-88.
J M
K N
L
