Installing the Car Seat:
With Vehicle Seat Belt
Before you install the car seat in your
vehicle, make sure the vehicle is parked on
level ground.
1. Attach the Side Impact Braces in a rear-
facing position: see pages 47-49.
2. Position the car seat rear-facing on the
vehicle seat. The car seat should face
the rear of the vehicle. The FRONT OF
VEHICLE arrow on the braces should
point to the front of your vehicle (Photo
A).
3. If the vehicle seat back is adjustable,
lock the vehicle seat back into the
upright position.
4. Center the car seat on the vehicle seat
(Photo B), making sure the areas under
and behind the car seat are clear of
obstructions.
5. Check that the car seat is level by
looking at the level indicator on the Side
Impact Brace (Photo C). The white
indicator ball must be in the blue level
zone on the brace (Photo D). If the white
indicator ball is not in the blue level zone
(Photo E), try any of the following:
Remove the car seat. Position a a.
rolled towel under the back of the
brace (Photo F). The towel should
be compressed as the LATCH belt is
tightened.
Install the car seat in a different
b.
vehicle seating position.
Seek assistance from one of the
c.
resources in the Need Help Securing
Your Car Seat? section.
⚠WARNING⚠
Death or Serious Injury Can Occur
To prevent ejection, the car
seat must be properly reclined.
The white level indicator ball in
the brace must be in the blue
level zone when installed.
D
E
F
A
B
C
