7
1.4.1 Connecting your OPR3301 to an iPhone/iPad/iPod *
This feature requires RFJ35534 with OS version RBGV0220 or higher.
*Note: iOS 4.0 or higher is required
The first step of connecting your OPR3301 is to put it into Bluetooth HID mode and
reading the 'Connect to PC' label (see also chapter 1.1).
Bluetooth HID
Connect to PC
(or another third party Bluetooth device)
Use the left label below to put your OPN2002 in iPhone/iPad mode. This makes it possible
to toggle the on-screen keyboard while being connected by double-clicking on the trigger
key*.
* Use the small button on the OPN2002 to toggle the onscreen keyboard.
_+-IOSON-+_ _+-IOSOFF-+_
Enable iPhone/iPad mode Disable iPhone/iPad mode
Pressing the trigger key will now also wake up the iPhone/iPad from standby. It is
recommended to disable the passcode lock option to prevent barcodes from being
entered as passcode when waking up from standby.
When using the OPR3301 as Bluetooth keyboard, the remote device always has to
make the first connection attempt (for security reasons). For this reason you will have
to make your OPR3301 discoverable and connectable to allow the iPhone/iPad to find,
pair and connect to your OPR3301.
To make your OPR3301 discoverable and connectable (for 2 minutes) read the label
below (this label can also be found in chapter 2.3.1 of the Universal menu book).
Make discoverable and
connectable
_+-DSCO-+_
When this is done, turn on Bluetooth on your iPhone. The iPhone will now automatically
discover your OPR3301. Once discovered, select the OPR3301 on your iPhone.
Once chosen, the OPR3301
’s laser will light up and you will hear a steady beep. Use the
number barcodes provided in chapter 1.4 to scan the displayed pin code; one number at a
time. When you are done, scan
‘END’ to complete the pairing.
Your OPR3301 is now paired and connected. The LED blinks blue slowly to indicate a
connection is active and working. Any barcode data you scan will now appear on the screen
as if you had typed it. Please have an application open that allows typing data.
Note, if for any reason your OPN2002 becomes unpaired with your other device (e.g. host
device goes to sleep, battery loss, etc.), you can simply hold the scan key for five seconds
to reestablish the connection.
