62
Byte Bit Bit-info Digilyzer Explanation
Channel status Quick view
3 0-3 0110 FS=24.0kHz 24.0kHz
0100 FS=48.0kHz 48.0kHz
0101 FS=96.0kHz 96.0kHz
0111 FS=192kHz 192.0kHz
1100 FS=32.0kHz 32.0kHz
1000 FS NO ID FS_NOID
others FS RSRVD FS_RESERVD
3 4-5 Clock accuracy
00 ACC:LVL2
+-1000PPM
01 ACC:LVL3
VARIPITCH
10 ACC:LVL1
+/- 50PPM
11 ACC:RSRVD
---------
4 1-3 Word length
000 WLEN NO ID ----- applicable if byte 4,
001 WLEN 23BIT 23BIT bit 0 is “1“
010 WLEN 22BIT 22BIT
011 WLEN 21BIT 21BIT
100 WLEN 20BIT 20BIT
101 WLEN 24BIT 24BIT
110 WLEN RSRVD -----
111 WLEN RSRVD -----
000 WLEN NO ID ----- applicable if byte 4,
001 WLEN 19BIT 19BIT bit 0 is “0“
010 WLEN 18BIT 18BIT
011 WLEN 17BIT 17BIT
100 WLEN 16BIT 16BIT
101 WLEN 20BIT 20BIT
110 WLEN RSRVD -----
111 WLEN RSRVD -----
4 4-7 Original sampling frequency
1111 ORIGNAL FS=44.1kHz
1110 ORIGNAL FS=88.2kHz
1101 ORIGNAL FS=22050Hz
1100 ORIGNAL FS=176400
1011 ORIGNAL FS=48.0kHz
1010 ORIGNAL FS=96.0kHz
1001 ORIGNAL FS=24.0kHz
1000 ORIGNAL FS=192kHz
Appendix
