55
Logger Event Coding
The following chart lists all details to the Digilyzer Logger event coding.
The remark column states:
• Any format not applicable (n.a.) for the individual events
• Maximum amount of events indicated per second (rec./s) or
“sample“ (= each sample is counted)
Appendix
description
Carrier based events
Digilyzer is not able to lock to the
input.
Sample frequency in 1C2f mode is
to high.
The received data eye pattern
opening is less than half of a bit period
(problems on the transmission line).
Violation of the biphase-mark format
of the carrier signal.
A change of the carrier level greater
than 100mV generates this event.
Details about the carrier level (aver-
age, min. and max. carrier level) are
also acquired.
A change of the carrier frequency
greater than 1 Hz generates this
event. Details about the carrier fre-
quency (min. and max. carrier fre-
quency) are also acquired.
Frame based events
Validity bit set. This happens e.g.
at a CD player with active error
correction.
DL1 event
Cr uNLoCK
Cr LoCK
Cr Fs To HIGH
Cr
CoNFIdeNCe
CR BI-PHASE
Cr LeveL
Cr
FreQueNCY
Fr vALIdITY
remark
10 rec./s
10 rec./s
10 rec./s
n.a. ADAT,
10 rec./s
n.a. ADAT
&TOSlink,
1 rec./s
1 rec./s
n.a. ADAT,
sample
