Byte Bit Bit-info Digilyzer Explanation
Channel status Quick view
3 0-2 Channel identification
000 MCMD0 CH MCMD0 Mode 0
001 MCMD? CH ----- Reserved
010 MCMD2 CH MCMD2 Mode 2
011 MCMD? CH ----- Reserved
100 MCMD1 CH MCMD1 Mode 1
101 MCMD? CH ----- Reserved
110 MCMD3 CH MCMD3 Mode 3
111 MCUSR CH MCUSR User defined
4 0-1 Digital audio reference signal
00 NO REF SIG No reference signal
01 GRAD 1 REF Grade 1 ref. signal
10 GRAD 2 REF Grade 2 ref. signal
11 REFS RSRVD Reserved
3-6 Extended sampling frequency
0000 FS NO ID FS_NOID Not indicated
0001 FS RESERVD FS_RSVD Reserved
0010 FS RESERVD FS_RSVD Reserved
0011 FS RESERVD FS_RSVD Reserved
0100 fs=96kHz 96.0kHz
0101 fs=88.2kHz 88.2kHz
0110 FS RESERVD FS_RSVD Reserved
0111 FS RESERVD FS_RSVD Reserved
1000 fs=24kHz 24.0kHz
1001 fs=22050Hz 22050Hz
1010 FS RESERVD FS_RSVD Reserved
1011 FS RESERVD FS_RSVD Reserved
1100 fs=192kHz 192kHz
1001 fs=176400 176kHz
1110 FS RESERVD FS_RSVD Reserved
1111 FS USERDEF FS_USER User defined
7 Sampling frequency scaling flag
0 FS * 1.000 No scaling
1 FS / 1.001 Scaling 1/1.001
