Audio data: The two lines represent the 20 bit audio word for both
channels.
• LSB on the left side, least significant bit
• MSB on the right side, most significant bit
The right bits always have to be active. In case some of the left bits
are constantly 0, the resolution of the audio signal is obviously less
than the maximum of 24 bits (including the aux. bits). The number
of arrows from right to left may be counted to find the actual word
length or binary resolution.
Measurement Functions
Application hints:
• Any digital input signal causes that some of the MSB’s are
active. The Digilyzer counts the number of active bits and
displays the result as actual word length.
• Sometimes bits of the input signal are stucked on “0“ or “1“.
In such a case a device in the signal chain is defective, e.g.
a receiver or a transmitter.
