Display
Meaning
Lights up:
F
F:
Stands for function
• If an operator function is carried
out.
• Always in combination with
a numerical value, which represents
the function type. (see page 52
Section 4.4.2 Function codes)
I
I:
Stands for infrared
transmitter.
• The operator functions are carried
out with active infrared control
mode.
• Always in combination with the
display F, for function and a numerical
value, which represents the function
type.
The code numbers of this function type
can be found on page 57-58 Section
4.4.6 Cockpit display with infrared
control.
H
H:
Stands for manual control.
• The operator functions are carried
out with active cable control mode.
• Always in combination with the display
F, for function and a
numerical
value, which represents the function
type.
The code numbers of this function type
can be found on page 53-54 Section
4.4.3 Cockpit display with cable
control.
E
E:
Stands for error.
• If a function has an error
• Always in combination with
a numerical value, which
represents the function type.
The error codes can be found on
page 98-99 Section 10.0 Malfunction
table.
Err: Stands for error
• If special errors occur.
The error codes can be found on
page 98-99 Section 10.0 Malfunction
table.
0.0
Operating hour meter
• 1 second after the function test of
the display (888888).
• Flashes alternating with the starting
function S. -- 05, until the engine
has started or the cockpit switches
to stand-by.
Display and operating elements:
