RX 1510-C/-I/-CI
– 11 –
2.6 Additional dangers 39
2.7 Emergency measures 39
3. Construction and function 40
3.1 Introduction 40
3.1.1 Basic information on soil compaction 40
3.2 Mechanical construction 40
3.3 Opening and closing of the hoods 41
3.3.1 Opening the cockpit hatch 41
3.3.2 Turning down the control unit 41
3.3.3 Opening and closing of the engine hood 41
3.3.4 Unlocking and opening the radiator cap 42
3.3.5 Components 43
3.4 Functional description 43
3.5 Safety and monitoring equipment 44
3.5.1 Shut down yoke 44
3.5.2 Low distance shutdown (only with infrared control) 44
3.5.3 Far distance shutdown (only with infrared control) 44
3.5.4 Inclination indicator 45
3.5.5 Automatic switch-off generator failure 45
3.5.6 Automatic switch-off oil pressure 45
3.5.7 Automatic switch-off cooling water temperature 46
3.5.8 Automatic speed adjustment 46
3.5.9 Transport protection 46
4. Display and operating elements 47
4.1 Introduction 47
4.2 Warning signals 48
4.3 Display elements 49
4.4 Operating elements 51
4.4.1 Manual control device 51
4.4.2 Function codes during operation with cable control 52
4.4.3 Cockpit display with cable control 53
4.4.4 Infrared transmitter 55
4.4.5 Function codes during operation with infrared control 56
4.4.6 Cockpit display with infrared control 57
