Multiquip RX 1510-C/-I/-CI User Manual
Page 43
RX 1510-C/-I/-CI
– 43 –
Control unit / Cockpit
Front car
Articulation
Rear end
Underframe
Drive unit
3.3.5 Components
3.4 Functional
description
The drive unit consists of a diesel engine, vibration, and driving pump. It provides
the required hydraulic performance for the driving, steering, and vibration
functions.
The valve block with the integrated control valves guides the output provided by
the driving unit to the connected consumers.
Construction and function
