aR13Ha/aR13HaR ROLLeR (s/n 110301 & up) • OpeRaTiOn anD paRTs manuaL — Rev. #0 (06/22/11) — page 9
speCifiCatiOns
Table 1. specifications (Roller)
Shipping Weight 2,572 lbs. (1,167 Kg.)
Dry Weight 2,428 lbs. (1101 Kg.)
Operating Weight 3,088 lbs. (1,400 Kg.)
Operating Weight w/ Drum Ballast 3173 lbs. (1,439 Kg.)
Overall Length 85 in. (2,159 mm.)
Overall Width 38.25 in. (972 mm.)
Overall Height-ROPS (up) 88 in.(2235 mm.)
Maximum Rolling Width 35.7 in. (907 cm.)
Turning Radius-Inside 109 in. (2,768 mm.)
Ground Clearance 11.5 in. (292 mm.)
Curb Clearance 7.75L, 19.0R (197 mm., 483 mm.)
Wall Clearance 1.75L, 1.25R (45 mm., 32 mm.)
Wheelbase 45 in. (1,143 mm.)
Drum Width 35.7 in. (907 mm.)
Drum Diameter 22.6 in. (574 mm.)
Drum Thickness 0.38 in. (10.0 mm.)
Centrifugal Force 2,400 - 2,700 rpm 3,100 Lbs. (1,406 Kg.)
Vibrations per minute 2,400 - 2,700 rpm 4,000 VPM
Dynamic Linear Force
per Drum 2,400 - 2,700 rpm
87.5 Lbs./in. (39.6 Kg./cm.)
(front only)
Oscillating Angle 11 degrees
Hydraulic Oil Tank Capacity 5.7 U.S. Gallons (21.6 Liters)
Cooling System Air
Fuel Gasoline
Fuel Tank Capacity 9.5 U.S. Gallons (36 Liters)
Water Tank Capacity 40 Gallons (181 Liters)
Battery 12 Volt Group Type U1
Travel Speed -variable- 0-4.8 MPH (0-7.7 KPH)
Grade Ability w-w/o Vibration 15 degrees (27%)
