aR13Ha/aR13HaR ROLLeR (s/n 110301 & up) • OpeRaTiOn anD paRTs manuaL — Rev. #0 (06/22/11) — page 65
ManifOld and HydrauliC Oil filter assy.
nO.
paRT nO.
paRT name
QTY.
RemaRKs
83
513334
HOSE
1
87
513335
HOSE
2
106
507278
HYDRAULIC TANK CAP
1
108
506218
STRAIGHT FITTING 3/4"
1
110
506221
FILTER, GAS
1
112
508667
OIL FILTER
1
114
508664
FILTER, HEAD
1
116
492357
SCREW HHC 1/4- 20X12
2
118
2101402
WASHER, LOCK 1/4” .......................................2................REPLACES 492622
119
EM25507
FITTING
3
120
506204
FITTING
1
122
506244
BLOCK FILTER M10
1
124
508670
VALVE CHECK
1
126
505976
CLAMP 3/4
5
128
506185
PLATE CORNER
4
130
492367
SCREW, HHC5/16”-18X1-3/4”
3
132
EM923343
WASHER, LOCK 5/16” .....................................4................REPLACES 492623
134
492371
BOLT 5/16” LOCK
1
136
506201
FITTING, TEE
1
138
506202
FITTING
2
140
506206
FITTING
1
142
508472
FITTING
1
144
506195
FITTING
1
156
515502
MANIFOLD
1
157
508814
BOLT 5/16”X3-1/4”
2
158
506192
FITTING
2
160
507774
VALVE RELIEF, 500 PSI
1
162
507772
PLUG
1
164
506247
VALVE, NEEDLE
1
166
506246
VALVE, RELIEF, 2000 PSI
1
168
506245
VALVE, SOLENOID
1
170
507885
12 VOLT COIL SOLENOID
1
172
506182
COUPLING PSI TEST
3
174
506190
FITTING
2
176
511808
ADAPTER, STRAIGHT
2
178
506190
FITTING
2
181
506195
FITTING
1
182
506205
PLUG
1
183
506193
FITTING
4
184
506195
FITTING
2
