aR13Ha/aR13HaR ROLLeR (s/n 110301 & up) • OpeRaTiOn anD paRTs manuaL — Rev. #0 (06/22/11) — page 79
sCrapper assy.
nO. paRT nO. paRT name QTY. RemaRKs
106 513290 SCRAPER, SUPPORT 4
108 508433 SCRAPER, RUBBER 4
110 508434 PLATE BACKING 4
112 EM963057 BOLT 3/8” ..........................................................12...............REPLACES 492313
114 3019092 WASHER, FLAT3/8” ..........................................12...............REPLACES 492598
116 EM969013 NUT, LOCK 3/8” ................................................12...............REPLACES 492583
118 EM963692 BOLT, 1/2” UNC X 1-1/2” ....................................8................REPLACES 492384
120 492584 NUT, LOCK 1/2” NC 8
122 621 WASHER 1/2” SPECIAL 8
