page 10 — aR13Ha/aR13HaR ROLLeR (s/n 110301 & up) • OpeRaTiOn anD paRTs manuaL — Rev. #0 (06/22/11)
speCifiCatiOns
Table 2. specifications (engine)
Model
Honda GX630RQZB2 Engine
Type
Air-Cooled 4 Stroke, Overhead Valve, 2 cylinders
(90 degree V-Twin), Gasoline Engine.
Piston Displacement
37.5 cu. in. (614 cc)
[Bore x Stroke]
[3.03 in. x 2.60 in. (77 mm x 66 mm)]
Max. Output
20 hp (13.4 KW, 18.3 PS) at 3,600 rpm
Max. Governed Speed, No Load
3,500 rpm
Max. Torque
31.8 lbf-ft. at 2,500 rpm
Cooling System
Forced Air
Engine Oil
SAE-10W-30 for general use
Engine Oil Capacity (with oil filter replacement)
1.90 qts. (1.80 liters)
Engine Oil Capacity (without oil filter replacement)
1.59 qts. (1.50 liters)
Fuel
Unleaded gasoline
Fuel Consumption
0.51 lb/hph (313 g/kWh, 230 g/PSh)
Spark Plug Type
NGK: ZGR5A
DENSO: J16CR-U
22.6 in. (574 mm.)
Idle Speed
1,400 +/- 150 rpm
PTO Shaft Rotation
Counterclockwise
