aR13Ha/aR13HaR ROLLeR (s/n 110301 & up) • OpeRaTiOn anD paRTs manuaL — Rev. #0 (06/22/11) — page 57
HOOd and rear panel assy.
nO.
paRT nO.
paRT name
QTY.
RemaRKs
2
515096
HOOD
1
6
492364
SCREW, HHC 5/16 X 18 X 1 IN.
2
8
505679
FLAT WASHER 5/16 IN.
2
10
2105164
NUT, NYLON 5/16- 18 .......................................2................REPLACES 492582
12
EM514610
LATCH KIT, STEEL
2
13
503723
RIVET BRAKE LINING
13
15
515199
SEAL RUBBER
1
16
513305
HINGE, SLOTTED
1
18
514438
LATCH KIT (HOOD)
1
22
492356
BOLT 1/4 X 3/4 IN.
12
24
492581
NUT 1/4 IN.
12
30
513396
FRONT CHASSIS
1
32
513308
REAR ENGINE COVER
1
33
13212
GROMMET, 1-1/4 IN. ID
1
34
513309
BOLT 5/16 X 3/4 IN.
4
86
513312
BOLT 1/4 X 1 IN.
2
88
492581
NUT 1/4 IN.
2
90
490181
SIGHT GLASS
1
92
513313
SUPPORT REAR ENGINE COVER
1
94
492356
BOLT 1/4 X 3/4 IN.
1
96
2101402
WASHER, LOCK 1/4 IN. ....................................1................REPLACES 492622
98
492596
FLAT WASHER 1/4 IN.
3
100
011208025
BOLT 8 X 25T DCA-85,125,150SSM .................1................REPLACES 508342
102
EM923343
WASHER, LOCK 5/16 IN. ..................................1................REPLACES 492623
104
506205
PLUG
1
146
506273
SOLENOID, STARTER
1
148
510925
NUT 3/16 IN.
2
150
513314
BOLT 1/4 X 1/2 IN.
2
152
492596
FLAT WASHER 1/4 IN.
2
154
492581
NUT 1/4 IN.
2
155
506085
GROMMET
1
156
31750Z2E8020
RECTIFIER ASSY, REGULATOR , 20A
1
157
32105Z6LA002
SUB-WIRE HARNESS ASSY.
1
