aR13Ha/aR13HaR ROLLeR (s/n 110301 & up) • OpeRaTiOn anD paRTs manuaL — Rev. #0 (06/22/11) — page 69
water tank assy.
nO.
paRT nO.
paRT name
QTY.
RemaRKs
8
513316
WATER TANK
1
10
EM963055
BOLT 3/8”X3/4” ..................................................1................REPLACES 492373
12
3019092
WASHER, FLAT 3/8” SPECIAL ..........................1................REPLACES 492598
13
0166A
WASHER, LOCK 3/8” ........................................1................REPLACES 492624
14
509249
WATER TANK CAP
1
16
506094
PLUG 1/2” NPT GALVANIZED
1
18
506071
ELBOW PVC
7
84
513321
WATER VALVE EXTENSION
1
88
492358
BOLT 1/4" NC x 1-1/4" G5
4
90
492581
NUT1/4"
4
92
513322
VALVE, BALL
2
93
813351
ELBOW 90G 1/2” NYLON
1
94
513379
“T” ADAPTER
1
98
506086
U- BOLT 3/8"
4
100
3019092
WASHER, FLAT. 3/8”.........................................16...............REPLACES 492598
102
508435
LOCK NUT
8
104
503015
KNOB, HANDLE ADJ.
2
116
504163
HOSE 1/2"
1
118
504163
HOSE 1/2"
1
119
504163
HOSE 1/2"
1
120
504163
HOSE 1/2"
1
122
504163
HOSE 1/2"
1
128
506084
CLAMP
4
130
505679
NUT 5/16"
4
132
505401
SCREW, HHC 5/16”- 18X1/2”
4
266
506072
PVC TUBE
4
268
506074
MALE ADAPTER
4
270
508610
CAP
4
