aR13Ha/aR13HaR ROLLeR (s/n 110301 & up) • OpeRaTiOn anD paRTs manuaL — Rev. #0 (06/22/11) — page 75
Brake COntrOl assy.
nO.
paRT nO.
paRT name
QTY.
RemaRKs
36
506046
LEVER, BRAKE
1
38
506158
BOLT 5/16" NC x 3/4" G5
4
40
492365
BOLT 5/16" NC x 1/1/4" G5
1
42
EM923023
WASHER, FLAT 5/16” ........................................2................REPLACES 492597
44
2105164
NUT, NYLON 5/16”- 18 ......................................1................REPLACES 492582
46
506057
BRAKE LINK
1
48
505999
BELL CRANK
1
50
EM963097
BOLT 3/8” NC x 1/1/2" G5 .................................1................REPLACES 492313
52
EM969013
NUT, LOCK 3/8” .................................................1................REPLACES 492583
56
508674
BOLT 5/16" NC x 1" G5
4
58
506042
PIN, CLEVIS
1
66
2219
KEY, COTTER
1
68
492570
NUT, HEX 5/8"
1
70
EM923348
WASHER, LOCK 5/8” .......................................1................REPLACES 492627
72
508449
BRAKE ROD
1
74
508619
BOLT, HEX HEAD 3/8” NCX4”
1
76
3019092
WASHER, FLAT 3/8” ..........................................2................REPLACES 492598
78
EM969013
NUT, LOCK 3/8” .................................................1................REPLACES 492583
82
506001
BUSHING, PLASTIC
1
265@ 513320
SUPPORT, BRAKE SHOE
1
266@ 505997
BRAKE PAD
1
267@ 508566
RIVET
6
268@ 508386
WASHER 3/16"
6
269
513193
BRAKE PAD ASSY. ............................................1................INCLUDES ITEMS W/@
