aR13Ha/aR13HaR ROLLeR (s/n 110301 & up) • OpeRaTiOn anD paRTs manuaL — Rev. #0 (06/22/11) — page 77
Battery assy.
nO.
paRT nO.
paRT name
QTY.
RemaRKs
144
514391
BATTERY 12V
1
146
513446
CABLE (-) BATTERY
1
148
513445
CABLE (+) BATTERY
1
150
505624
BATTERY TERMINAL COVER ..........................1................BLACK
152
506266
BATTERY TERMINAL COVER ..........................1................RED
154
506152
WRAP
1
156
506151
CLAMP, BATTERY
1
158
492354
HEX HEAD SCREW 1/4"X1 1/2" NC G5
1
160
3019092
WASHER, FLAT 3/8” ..........................................1................REPLACES 492598
