aR13Ha/aR13HaR ROLLeR (s/n 110301 & up) • OpeRaTiOn anD paRTs manuaL — Rev. #0 (06/22/11) — page 49
frOnt druM assy.
nO.
paRT nO.
paRT name
QTY.
RemaRKs
2
513280
FRONT ROLLER
1
4
506145
HOUSING BEARING
1
6
506147
BEARING
1
8
506136
RING, RETAINING
1
10
508665
COUPLER
1
12
506142
MOUNT, VIBRATION MOTOR
1
14
011208025
BOLT, 8X25T ......................................................6................REPLACES 508342
16
EM923023
WASHER, FLAT 5/16" ........................................6................REPLACES 492597
18
492264
BOLT, 3/8"X1"
6
20
506141
SHOCK, MOUNT
3
22
508340
STUD, M8X40
6
24
EM923343
WASHER, LOCK 5/16........................................6................REPLACES 492623
26
020108060
NUT, M8 .............................................................6................REPLACES 508341
28
514522
ROLLER, SUPPORT .........................................1................RIGHT SIDE - FRONT
30
492276
BOLT 1/2" X 1-1/2"
8
32
513283
HOSE, PROTECTION COVER
1
34
513314
NUT 1/4" X 3/4"
12
36
506220
MOTOR, HYDRAULIC
1
40
492362
NUT 5/16" X 5/8"
4
41
EM923343
WASHER, LOCK 5/16" ......................................4................REPLACES 492623
43
513337
HOSE
1
45
513343
HOSE
1
47
513342
HOSE
1
78
EM963610
CAPSCREW 3/8" NC X 1-1/4" G8 .....................6................REPLACES 492375
80
3019092
WASHER, FLAT 3/8" ..........................................6................REPLACES 508346
82
517389
SHOCK MOUNT, 3" DIAMETER
6
84
021110120
NUT, NYLON LOCK M10 ZINC 1.SP
6
86
505977
PLATE, DRIVER
1
88
505984
HUB
1
90
EM503803
PINS, DOWEL....................................................2................REPLACES 503803
92
515637
SUPPORT, ROLLER ..........................................1................LEFT SIDE - FRONT/REAR
94
EM924006
KEY, COTTER 1/8" X 2" .....................................1................REPLACES 491690
96
515396
MOTOR, HYDRAULIC
1
98
505990
BOLT 1/2" X 2-1/2"
4
100
515639
COVER
1
124
505951
FITTING
2
126
513332
FITTING
2
128
515641
HOSE
1
130
513344
HOSE
1
