a) From the Station Manager application main window, click the Manual Command button to bring up
manual controls.
b) Select the following parameters:
• Channel — Ch1 (or other depending on your configuration)
• Control Mode — Force
• Enable Manual Command — Checked
c) Type 0.00 in the Manual Cmd text box and press Enter.
3. Switch to Displacement control mode.
This prevents unwanted movement of the actuator.
a) From the Station Manager application main window, click the Manual Control button.
b) In the Manual Controls' window Control Mode drop down list, select Displacement.
4. Release the upper grip.
Use the controls on the load frame.
5. Retract the actuator.
MTS Landmark Test System Operation | 99
Running the Example HCF Test
