Ce hardware specifications, Ce hardware specifications 19 – MTS 709 Alignment System User Manual
Page 19
Additional Information
709 Alignment System
Introduction
19
CE Hardware Specifications
P
ARAMETER
S
PECIFICATION
Environmental
Ambient Temperature
Relative Humidity
Altitude
For Indoor Use Only
5°C (41°F) 40°C (104°F)
10% to 85%, non-condensing
For use at altitudes up to 2000m (6500 ft.)
Power Input
Input Voltage
Input Frequency
AC Power
Insulation Over
Voltage
Pollution Degree
Power Factor Corrected Universal Input
100 to 240 VAC
47 to 63 Hz
< 100 Watts
Category II
2
AC Power Disconnect
Remove the AC power cord from the power supply.
This will remove AC power from the 709 Alignment
System.
Be sure to locate the power supply so you have
adequate access to disconnect the power cord from
the power supply.
