MK Diamond MK-2000 Pro - Manual (Page 42)

MK-2000 Pro Revision 01/02, Effective Date January 10, 2002 Page 42
EXPLODED VIEW AND PARTS LIST
Item Description Qty MK P/N
SD Assembly, Mtr 110/220v 1 Ph 60 Hz 3 hp n/a
SD1 Motor, 115/230v 60 Hz 3 hp (saw duty) 1 158752
SD2
SD3 Pulley, 2 Groove, 2 –1 /2 x 3/4
Screw, 5/16-18 x 1/4, Set 1
2 231083
231239
SD2
SD3 Pulley, 2 Groove, 2 –1 /2 x 3/4
Screw, 5/16-18 x 1/4, Set 1
2 231083
231239
SD4 Key, 1 - 1/8 x 3/16 1 150344
SD5 Receptacle, 20 Amp 115 volt 1 154621
SD6 Switch, Voltage Change 1 150577
SD7 Switch, Thermal Overload TPMlSJ24AB 1 153503
SD8 Box, Switch 1 139758
SD9 Switch, On/Off 30 Amps/250 volts 1 139741
SD10 Cover, Switch Box 1 139766
SD11 Screw, 10-32 x 1/4, Slotted Round Head Machine 4 231090
SD12 Screw, 1/4 - 20 x 3/4 Hex Head 2 152676
SD13 Capacitor, HSG 1 150574
SD14 Capacitor, Oil MK2000 OC3020F12 1 152412
SD15 Plug, Twist Lock 20 Amp125 volt (NEMAL520P) 1 154556
SD16 Nut, 5/16-18 w/ External Tooth Washer 4 153942
SD17 Washer, 5/16 SAE, Flat 4 151754
SD18 Warning, Cord Selection 2 3/4 x 2 1/2 1 155672
SD19 Caution, Ground Fault Interrupter 2 1/8 x 1 1 155678
SD20 Attachment for Water Pump 1 1/2 x 3/4 1 154408
SD21 Motor, Cool Push 1 x 5/8 1 154409
