MK-2000 Pro Revision 01/02, Effective Date January 10, 2002 Page 36
MAINTENANCE AND TROUBLESHOOTING
NOTE: “Rodding” cooling channels is performed by inserting a small wire rod through the cooling inlet on top
of the Blade Guard and directing the rod out through each of the cooling flow tubes located on the
underside o the Blade Guard. The cooling channels should be “rodded” until all ports are free of
foreign debris.
(H)
Remove the Pump Casing and
check for restriction; check
Impeller damage
(G)
Remove the 3 Pump Casing
Retaining Screws
Check Impeller
for damage
Phillips
Screwdriver
Check for
restriction
If no damage
or restrictions,
go to Step I
Once Screws removed
go to Step H
(J)
Attach the Flow Control Valve
to the Intake Fitting and check
flow (See Step C)
(K)
Rod Cooling Channels and
recheck flow; if after performing
Steps A to N flow still does not
exist, go to Step L
Rod
Channels
Go to
Step M
Turn counter-
clockwise to loosen
Cooling Flow
Control Valve
3/4- inch
Wrench
(I)
Using a 9/16-inch wrench,
remove the Flow Control Valve
from the Blade Guard
Go to
Step N
Cooling Flow
Control Valve
Go to
Step O
Return to
MK Diamond
for Repair
(L)
Return to MK Diamond
