EXPLODED VIEW AND PARTS LIST
Item Description
Qty
MK
P/N
E Assembly,
Pivot Shaft 1
assign
E1
Shaft, Pivot
1
154147
E2
Collar, Pivot Shaft
2
140012
E3
Bracket, Stay-Level
1
231234
E4
Spring, Torsion (4 coil)
1
231038
E5
Bracket, Pivot Shaft Retaining
1
231023
E6
Screw, 5/16-18 x 1 Button Head
4
151698
E7
Washer, 5/16 SAE Flat
4
151754
E8
Washer, 5/16 Split Lock
4
151747
F Assembly,
Cutting Head Height Adjustment 1
n/a
F1
Knob, Tri (w/ 3/8-16 x 2 1/2 Stud)
1
231039
F2
Washer, 3/8 SAE Flat
1
150923
F3
T-Nut
1
231040
F4
Bracket, Height Adjustment
1
156839
F5
Screw, 1/2 x 1/2 Socket Hd. Shoulder, (3/8-16 x 1/2 Thread)
1
151753
F6
Washer, 1/2 SAE Flat
2
150923
G Assembly,
Blade Shaft 1
n/a
G1
Blade Shaft-Arbor, Complete
1
153791
G2
Bearing, Blade Shaft
2
154594
G3
Shaft, Arbor
1
154639
G4
Flange, Inner
1
154640
G5
Flange, Outer 14 Inch M-Saw
1
132290
G6
Screw, 1/2-20 x 1 1/4, Hex Head Cap
1
152122
G7
Pin, Arbor Alignment
2
153946
G8
Washer, 5/16 Split Lock
4
151747
G9
Washer, 5/16 SAE Flat
4
151754
G10
Screw, 5/16-18 x 2 1/4
4
153951
G11
Pulley, 2 Groove, 2-1/2 x 5/8
1
133157
G12
Key, 1 1/8 x 3/16
1
150344
H Assembly,
Blade Guard 1
n/a
H1
Blade Guard
1
158886
H2
Stud, Blade Guard Pivot
1
150581
H3
Nut, 1/2-20 Lock
1
153943
H4
Shim, 1/2
1
153952
H5
Rod, Adjustment Blade Guard
1
231052
H6
Ball Joint Rod End, Stamped, 3/8-24
2
156521
H7
Nut, Jam 3/8-24
2
231054
H8
Screw, 3/8 x 1/2 Shoulder, 5/16-18 x 1/2 Thread
2
231246
H9
Valve, Miniature Ball, 1/4 Male / Female
1
231248
H10
Tag, Serial
1
157007
H11
Tack, Metal 1/4 Hd.
2
155659
H12
Label, Warning, Blade Guard Failure
1
155588
J Assembly,
Splash Guard
n/a
J1
Curtain, Blade Guard
1
152417
J2
Bracket, Water Curtain
1
152723
J3
Screw, 1/4-20 x 1/2, Hex Head Cap
1
152608
J4
Washer, 1/4 SAE Flat
1
151915
