Exploded view and parts list – MK Diamond MK-2000 Pro User Manual
Page 38
MK-2000 Pro
Revision 01/02, Effective Date January 10, 2002
Page 38
EXPLODED VIEW AND PARTS LIST
PARTS LIST:
Item Description
Qty
MK
P/N
A Assembly,
Frame, Brick Saw 1
n/a
A1
Frame, Weldment
1
158845
A2
Plug, Rubber Drain
1
153439
A3
Label, MK 2000 Brick Saw
2
155230
B Assembly,
Upright, Left 1
n/a
B1
Post, Left
1
158846
B2
Screw, 5/16-18 x 1 3/4, Hex Head Cap
4
150919
B3
Washer, 5/16 Split Lock
4
151747
B4
Washer, 5/16 SAE Flat
8
151754
B5
Nut 5/16-18 Hex
4
101196
B6
Stud, Spring Retaining
1
231024
B7
Screw, 5/16-18 x 1 1/2, Hex Head Cap
1
152467
B8
Washer, 5/16 Split Lock
1
151747
B9
Washer, 5/16 SAE Flat
1
151754
C Assembly,
Upright, Right
n/a
C1
Post
1
158846
C2
Screw, 5/16-18 x 1 3/4, Hex Head Cap
4
150919
C3
Washer, 5/16 Split Lock
4
151747
C4
Washer, 5/16 SAE Flat
8
151754
C5
Nut 5/16-18 Hex
4
101196
C6
Hanger, Wrench
1
153945
C7
Screw, 3/8-16 x 1 3/4, Hex Head Cap
1
150920
C8
Washer, 3/8 SAE Flat
1
150923
C9
Washer, 3/8 SAE Split Lock
1
150925
C10
Clamp, Cushion Loop 1/2” (elec.)
1
152471
C11
Screw, 1/4-20 x 1 3/4 Hex Head Cap
1
231233
C12
Washer, 1/4 SAE Flat
2
151915
C13
Washer, 1/4 Split Lock
1
152591
C14
Nut 1/4-20 Hex
1
151893
D Assembly,
Cutting Head
n/a
D1
Casting, Cutting Head, Complete
1
150583
D2
Bar, Adjustment
1
150585
D3
Pin, Split Wrist
1
151358
D4
Bushing, Plastic
2
156441
D5
Stud, 5/16-18 x 1 1/2
6
153680
D6
Handle
1
139931
D7
Grip, Handle 7/8 I.D.
1
158608
D8
Screw, 3/8-16 x 3/4, Flat Socket Head Cap Screw
2
151752
D9
Strap, Motor Adjustment
1
150584
D10
Bolt, 3/8-16 x 3 1/2 Hex Head Cap
1
153147
D11
Washer, 3/8 SAE Flat
1
150923
D12
Stud, Pulley Alignment
1
231274
D13
Caution, Owners Manual 4 x 1 1/4
1
155576
