EXPLODED VIEW AND PARTS LIST
Item Description Qty MK P/N
K Assembly, Belt Guard 1 n/a
K1 Belt Guard Inner 1 150590
K2 Washer, 3/8 SAE Flat 2 150923
K3 Nut, 5/16-18 Hex (w/ external tooth washer) 2 153942
K4 Belt, V AX-32 2 151723
K5 Belt Guard Outer 1 158867
K6 Screw, 5/16-18 x 1 3/4, Hex Head Cap 2 150919
K7 Washer, 5/16 Lock Split 2 151747
K8 Washer, 5/16 SAE Flat 2 151754
K9 Caution, Guard Removal 3 x 1 1/2 1 155587
L Assembly, Splash Curtain 1 n/a
L1 Rod, Splash Curtain 1 153956
L2 Curtain, Rear 1 152417
M Assembly, Table 1 133082
M1 Table 1 153790
M2 Stop-Rule, Table 1 134387
M3 Screw, 1/4-20 x 3/4 Hex Head Cap 4 152504
M4 Nut, 1/4-20, Hex w/ External Tooth Washer 4 153941
M5 Wheel Roller 4 133090
M6 Nut, 5/16-18, Hex w/ External Tooth Washer 4 153942
M7 Wood Strip, Table Insert 1 156427
M8 Screw, Pan HD Phil. #8 x1 2 151047
M9 Sticker, Inspected By: (not shown) 1 n/a
N Assembly, Pump Electric 1 n/a
N1 Pump, Water G-150A 1 151271
N2 Adapter, Plastic MNPT x 1/4 FNPT 1 151018
N3 Hose, Vinyl 1/4 ID 3 Ft. 132951
N4 Owner’s Manual, Water Pump G-150A 1 155745
N5 Carton, Water Pump G-150A 1 154016
N6 Insert, Foam Water Pump G-150A 1 154017
P Assembly, Accessory Pack 1 n/a
P1 Wrench, Masonry Saw 1 134056
P2 Carton, Accessory (not shown) 1 153575
P3 Insert, Accessory (not shown) 1 153576
P4 Assembly, Rip Guide, Large
Rip Guide, Large (Comp)
Screw, 5/16-18 x 1 1/2 Thumb
Nut, 5/16-18 Square 1
1
1
1 n/a
132332
150303
151156
P5 Warranty Card 1 155037
P6 Sell Sheet, Tile Accessory 1 156915
P7 Owners Manual, MK-2000 Pro Series 1 158753
