UNPACKING, TRANSPORT, UNIVERSAL STAND and ASSEMBLY
5. Water Pump Preparation:
(A)
Thread the Water Pump
Discharge Fitting onto the
Water Pump discharge
Cooling
Transfer Tube
(B)
Press one end of the Cooling
Transfer Tube onto the Water
Pump Discharge Fitting
Press on
Flow Adjusting
Clamp
Press on
(C)
Slide Cooling Flow Adjusting
Clamp onto the Cooling
Transfer Tube
Turn clockwise
to tighten
Discharge
Fitting
Pump
Discharge
