MK-2000 Pro Revision 01/02, Effective Date January 10, 2002 Page 25
MAINTENANCE AND TROUBLESHOOTING
MAINTENANCE:
1. New Maintenance:
Perform the following after initial purchase and operation of the MK-2000 PRO.
2. Maintenance Following Use:
To extend the life of the MK-2000 PRO, the following procedure should be performed after each use.
Lubricate all points listed below with light oils such as, 3 in 1, WD-40, etc.
(C)
Lubricate the Movable Cutting
Table Roller Wheels
(D)
Lubricate the Blade Guard
Pivot Points
(A)
Check and adjust V-belt tension
following the first 48 hours of
operation (See V-belt Inspection)
(B)
Unplug the MK-2000 PRO
Polarized plug from the power
source by turning counter-
clockwise and then pulling
straight back
(A)
Ensure the ON/OFF Switch is
in the OFF position
Turn counter-
clockwise to unlock
Pull straight
back
Roller Wheel
(E)
Lubricate the Cutting Head
Pivot Points
Pivot Point
Pivot Point
Inspect
V-belt
ON/OFF
Switch
OFF
Position
