SETUP, ADJUSTMENT and OPERATION
2. Chop Cutting:
A Chop Cut is performed by cutting completely through an object in one pass.
Note: Skip steps E and F, if cutting dry.
(J)
Turn the Saw off when cutting
is complete
ON/OFF
Switch
OFF
Position
(C)
Verify the Masonry Piece is
seated against the Ruler/Stop
and the Adjustable Cutting Guide
(A)
Set the Adjustable Cutting Guide
to the desired length indicated
on the side of the Ruler/Stop
closest to the Wooden Strip
(D)
Place the ON/OFF Switch in
the ON position
(F)
Verify cooling flow exists on
both sides of the blade
(E)
Open the Cooling Flow Control
Valve and adjust cooling flow
Ruler
Markings
Measuring
point
Ruler/Stop Adjustable
Cutting Guide
(B)
Place the Masonry Piece onto
the Movable Cutting Table
ON/OFF
Switch
OFF
Position
Cooling Flow
Points
Masonry Piece Adjustable
Cutting Guide
Ruler/Stop Masonry Piece
Control Valve
